Frame: Atmos 95 flters are available in a variety of wood and metal frame materials such as particle board, plywood,galvanized steel and stainless steel. Atmos 95 flters are also available in 24 gauge corrosion resistant steel in single or double headers for installation in side access or plenum applications.
Seal: The standard gasket seal is 0.75” x 0.25” neoprene for installation on either the upstream, downstream or both sides of the flter. The standard Fluid Seal is WAT Blu-Jel ® Seal which is a two-part silicone material suitable for temperatures up to 390°F.
Faceguards: Faceguards are used to protect the flter media from mechanical damage. The typical faceguard material is expanded aluminized steel. Galvanized 4 x 4 mesh welded wire and Type 304 stainless steel faceguards are also available.
UL: Atmos 95 flters are either UL900 Class 1 or Class 2 listed depending on materials of construction.
Banks: Atmos Frames are designed for Atmos 95 flters in built-up flter banks. Each flter is secured in the frame with four bolt-type fasteners that either compress the gasket or press the knife edge into the gel in the flter channel to maintain a leak-tight seal. Surelock B or C-3 gasket seal and Surelock C-4 for Blu Jel HEPA Filter Housings are recommended for side-access applications. The flters are sealed in place with either spring-loaded swing arm assemblies or a locking mechanism. The swing arm assemblies or locking mechanism either compress the gasket or press the knife edge into the gel in the flter channel to maintain a leak-tight seal.
